BX-956S 盒式工控机 BX-956S - 无风扇嵌入式PC / 小型A5大小 / Atom E3845 (BayTrail SoC) / DC电源

标准保修3年
延长保修可能

Design that meets the safety standard
Slitless/fanless design that reduces maintenance work
Safety design required for embedded applications
Remote power management function to reduce operation tasks
Major types of peripherals are supported with rich interfaces including the two CFast card slots
Falling-off prevention tools and fixing clamps provided to avoid trouble caused by disconnected cable

*
有关延长保修的详细信息，请与我们联系。

机能・规格

机箱设计

设置方式	Desktop; Wall Mount

支持的软件

支持的操作系统	Windows 10 IoT Enterprise LTSB 2016 64-bit; Windows Embedded Standard 7 32-bit; -

核心系统

处理器	Atom E3845
CPU代数 (开发代码)	Bay Trail
CPU接口	-
内存	8GB; 4GB
RAS	-
GPU	-
AI Performance	-
安全特性	NIST SP800-147 (BIOS Write Protect); Secure Boot USB Key

外部接口

显示器	1x DVI-I
局域网	2x 1000BASE-T
Wireless	-
音频	1x Line out; 1x Mic-in
输入/输出	1x USB3.2 Gen1 (USB3.0); 5x USB2.0; 2x RS-232C
存储卡	2x CFast slots

扩展插槽

扩展总线	-
驱动器插槽	-

电源

输入电压	12 to 24VDC

设置环境

工作温度	0 to 60°C (32 to 140°F) (when using 1000BASE-T: 0 to 55°C (32 to 131°F) ) with 0.7m/s airflow; 0 to 50°C (32 to 122°F) (when using 1000BASE-T: 0 to 45°C (32 to 113°F) ) without airflow; * Derating may occur (Refer to Manual)
储存温度	-10 to 60°C (14 to 140°F)
认证标准/规格	CCC; CE; FCC Class A; UKCA; UL; VCCI Class A
