AI-1204Z-PCI Analog Input PCI Card / 4ch(12bit 10Ms/s)

Standard Warranty3 yrs
Extended WarrantyAvailable

Maximum conversion speed is 10MSPS (100nsec), with simultaneous sampling of 4channels at a time
Sampling can be controlled by software, conversion data comparison, external trigger, event controller output, and similar start and stop conditions
Incorporates a synchronization control connector for synchronized operation
Large (32M data) buffer memory and bus master transfer function allow continuous data acquisition at high speed for a long period

*
For details about an extended warranty, please contact us.

Supported OS

Similar Models

PCI Express card(Native support for 64bit Windows.)

Ordering Information

Ordering Information

Model	Description	Certification
AI-1204Z-PCI	Analog Input PCI Card / 4ch(12bit 10Ms/s)

Options

Device Drivers

Item	Item Name
API-AIO(WDM)	Windows version High-efficiency Analog I/O Driver

Development Support Tools

Item	Item Name
ACX-PAC(W32)	ActiveX components sets for measurement system development
DAQ-DNC-FE	A collection of .NET components for DAQfast measurement system development.
DAQ-LV-WIN	LabVIEW Data Acquisition Library
ML-DAQ	MATLAB compliant Data Acquisition Library

Applications

Item	Item Name
C-LOGGER	Data Logger Software for Windows

Cable

Item	Item Name
BNC-B	BNC cable (1m, 2m, 3m)
DT/E1	16pin Header to Open-Ended for Analog E series Boards-1.5m
DT-E3	16pin post header -> D-SUB 15pin Bracket with Cable(150mm)
PCA15P	15pin D-type(M) to Open-Ended, Flat Cable
PCB15P	15pin D-type(M) at Each-End, Flat Cable

Terminal

Item	Item Name
FTP-15	Screw Terminal (M3 x 15)

Extended Warranty Service

Item	Item Name
ESP-F6	Extended warranty service package (6 years service course) (Japan only)
