LPC-1700 超薄塔型计算机 LPC-1700 / Intel 8th Gen. (Coffee Lake + Q370) / 1x 3.5 英寸内部驱动盘架

• 概要・特点
• 机能・规格
• 订购信息・选件
• 技术支持・下载

概要・特点

This product is a slim tower type industrial computer that is equipped with an 8th generation Intel® Core™ processor series. The Intel® Q370 chipset with DDR4 memory 32GB provides advanced computing and graphical performance. This product features a variety of interfaces such as one each port of DVI-I, HDMI, DisplayPort, Six USB3.2 Gen1 (USB3.0) ports (front: 2,rear: 4), four USB2.0 ports (front: 2, rear: 2), one serial ports (RS-232C/422A/485×1), and three 1000BASE-T ports, which can be used in a wide range of embedded applications such as general-purpose PC OS-based controllers and information terminals. Expansion slots : PCI-Express(x16) slot x1, PCI-Express(x4) slot x2, PCI slots x1

应用实例

• Compatible with Intel ® Core ™ processor series Coffee Lake

  • The product is equipped with the 8th-generation Intel ® Core ™ processor and greatly realizes lower-power consumption while ensuring fine performance of operation tasks and drawing. Adopting embedded-type CPU contributes to a stable supply.
• High-performance graphics with CPU embedded type

  • Full HD video can be smoothly played with the Intel® HD Graphics 630. It also supports full HD output of the three-screen with the DVI-I, DisplayPort and HDMI.
• Rich variety of interfaces to expand your peripherals freely

  • Interfaces including DVI-I, HDMI, DisplayPort, 1000BASE-T x 3, USB3.2 Gen1 (USB3.0) x 6, USB2.0 x 4, serial port (RS-232C/RS-422A/RS-485 x 1), and audio are provided
• A GPU board can be installed. 4 expansion slots

  • It has 4 expansion slots (1x PCI Express (x16), 2x PCI Express (x4), 1x PCI), 1x PCIe Low Profile, length 160mm, GPU board up to 75W can be installed.
