SPF10SQ1700 工控机 SPF10SQ1700 - 壁挂式安装 PC / Intel 6th/7th Gen. Core (Skylake/Kaby Lake + Q170) / 1x PCIe(x16) / 7x PCI / AC电源

• 概要・特点
• 机能・规格
• 订购信息・选件
• 技术支持・下载

概要・特点

This product is a compact-sized industrial computer that is compatible with 6th-generation (Skylake) and 7th-generation (Kaby Lake) of Intel® Core™ series processors and adopts the Q170 chipset. In addition to a wide range of interfaces, the product also includes seven PCI bus expansion slots and one PCI Express (x16) bus expansion slot. The product adopts a reliable, Japan-made power supply (made by Nipron). Solution-ePC is an industrial-use computer that offers BTO (Build to Order) specifications to suit the requests of customers. Only carefully selected components offering high reliability and stable supply are used, making the product suitable for industrial use. Various selections and options are available to meet customer requests, including OS, CPU, memory, and storage options.

• Compatible with Intel ® Core ™ processor series Skylake/Kaby Lake

  • Available with a power-saving, high-performance 6th- or 7th-generation Core processor for advanced computation and drawing performance while minimizing power consumption.
• Compact wall-mounted design

  • The compact size allows for installation in spaces as small as 330 mm (W) x 408.8 mm (D) x 175 mm (H).
• CPU and chipset designed for embedded devices

  • The adoption of embedded CPUs and chipsets makes it possible to ensure supply stability.
• Expandable to up to eight PCI and PCI Express slots

  • Take advantage of seven PCI bus expansion slots and one PCI Express (x16) bus expansion slot.
• Rich variety of interfaces for freely expandable peripherals

  • It has a variety of extended interface such as PCI Express (×16) x 1slot, PCI x 7, DVI-I x 1, 1000BASE-T x 2, USB3.2 Gen1 (USB3.0) x 5 (Max.), USB2.0 x 2, serial (RS-232C) x 2 (Max.), serial (RS-232C/RS-422A/RS-485) x 2 (Max.).
• Supports also Windows 7 Pro and WES 7

  • If you select the 6th generation (Skylake) processor, it is possible to order a Windows 7 pre-installed model. You can use it to inherit the assets developed in Windows 7.
    • ※
      Microsoft's support period for Windows 7 has ended on January 14, 2020. At the end of the support period, you will no longer receive all support, including regular security updates and paid support.
