DIO-1616LN-FIT 数字量输入输出 F&eIT总线 I/O模块 16点/16点 (光电隔离, 输入12-24VDC，输出12-48VDC)

标准保修1年
延长保修可能

Optocoupler isolated inputs (for use with current sink output / current source output), Optocoupler isolated open-collector outputs (current sink type)
Fail safe function
Compact design not restricting installation location (188.0(W) x 78.0(D) x 30.5(H))
Compatible with a wide range of power supplies : 5 to 24VDC
Diverse installations such as screw fastening, magnet, DIN rail are possible
Windows compatible driver libraries are supported.

*
有关延长保修的详细信息，请与我们联系。

支持的操作系统

机能・规格

扩展模块

系列	F&eIT(省布线远程I/O)
总线规格	Ethernet
类型	N Type
所用连接器	-

数字信号输入和输出

输入点数	16-ch
输出点数	16-ch
双向输入输出点数	-
响应时间（输入）	1msec (max.)
响应时间（输出）	1msec (max.)
工作电压（输入）	12 to 24VDC
工作电压（输出）	12 to 48VDC
输入电路	Opto-isolated input (for both current sink and source output)
输出电路	Opto-isolated open-collector output (current sink type)
内置外部电路用电源	-

支持的操作系统

支持的操作系统	Windows 11 (64-bit); Windows 10 IoT Enterprise LTSC 2021 (64-bit); Windows 10 IoT Enterprise 2019 LTSC (64-bit); Windows 10 IoT Enterprise LTSB 2016 (64-bit); Windows 10 (64-bit); Windows 10 (32-bit); Windows 8.1 (64-bit); Windows 8.1 (32-bit); Windows 7 (64-bit); Windows 7 (32-bit); Windows Vista (64-bit); Windows Vista (32-bit); Windows XP (64-bit); Windows XP (32-bit); Windows 2000 (32-bit); Windows Server 2019; Windows Server 2016 ; Windows Server 2012 R2; Windows Server 2008 (64-bit); Windows Server 2008 (32-bit); Windows Server 2003 (64-bit); Windows Server 2003 (32-bit)

Windows 11 (64-bit); Windows 10 IoT Enterprise LTSC 2021 (64-bit); Windows 10 IoT Enterprise 2019 LTSC (64-bit); Windows 10 IoT Enterprise LTSB 2016 (64-bit); Windows 10 (64-bit); Windows 10 (32-bit); Windows 8.1 (64-bit); Windows 8.1 (32-bit); Windows 7 (64-bit); Windows 7 (32-bit); Windows Vista (64-bit); Windows Vista (32-bit); Windows XP (64-bit); Windows XP (32-bit); Windows 2000 (32-bit); Windows Server 2019; Windows Server 2016 ; Windows Server 2012 R2; Windows Server 2008 (64-bit); Windows Server 2008 (32-bit); Windows Server 2003 (64-bit); Windows Server 2003 (32-bit)

*
各个软件能够支持的操作系统是不同的。关于各个软件所支持的操作系统以及发行版本的信息，请参阅该软件的Readme文件和在线帮助程序。
