PT-M17SB-2500-G 触摸屏一体机 PT-M17SB-2500-G - 触摸屏PC / 面板安装式 / 17-inch LCD, 10-point P-CAP触屏 / Intel 9th Gen. Core (Coffee LakeRefresh + C246) / DC电源

• 概要・特点
• 机能・规格
• 订购信息・选件
• 技术支持・下载

概要・特点

This product is a high-performance embedded-type personal computer equipped with the 9th generation Intel® Core™ and Celeron® processor. Embedded-type chipset and CPU have been adopted. The use of readily available parts ensures the ease of the use of the product.
Positioned as a versatile solution for industrial automation, manufacturing, healthcare, retail, and more, the PT-M17SB-2500-G Touch Panel Computer is tailored to meet the demands of modern businesses. Its robust features, high-performance capabilities, and flexible mounting options make it an ideal choice for organizations seeking to enhance efficiency and productivity.

• Compatible with Intel® 9th Gen. Coffee Lake-Refresh Platform

  • This product is equipped with the 9th generation Intel® Core™ processor and greatly realizes lower-power consumption while ensuring fine performance of operation tasks and drawing. Adopting embedded-type CPU contributes to a stable supply. Three types of CPU are lined up.
    • Intel® Core™ i7-9700TE
    • Intel® Core™ i5-9500TE
    • Intel® Core™ i3-9100TE
    • Intel® Celeron® G4900T
• IP65 + True flat Front Panel Design

  • This product uses aluminum as the front baffle material and has IP65 certification. In addition to meeting waterproof and dustproof applications, the classic thin frame design can be widely used in various payment machines, information inquiry terminal facilities and automated factories.
• CPU Built-in High-Performance Graphics

  • Core i7, Core i5 ,Core i3, and Celeron Models are corresponded to the Integrated Intel® HD Graphics. Full HD video can be smoothly played. It also supports full HD output of the two-screen with the DVI-I and DisplayPort.
• Adopt Removable Storage

  • This product uses two 2.5-inch SATA storage trays on the front, supporting RAID functions such as mirroring. Ensure data security and maintenance convenience.
• Extend Peripherals Freely Rich Interface

  • This product is equipped with a variety of expansion interfaces such as DVI-I, DisplayPort, 1000BASE-T × 2, USB3.2 Gen 2 × 4, USB2.0 × 2, serial (RS-232C) × 3, serial (RS-232C/422A/485) × 1, audio.
