GMB-EAC62100 産業用マザーボード / EATX / Intel 3rd Gen. Xeon processors (Ice Lake-SP + C621A) / LGA 4189 (Socket P+) / 3x PCIe(x16), 2x PCIe(x8), 1x PCIe(x4)

• 概要・特長
• 機能・仕様
• 価格・オプション
• サポート・ダウンロード

概要・特長

This product is a EATX form factor industrial mainboard which based on Intel® 3th generation Xeon® Processor with Ice Lake-SP platform. GMB-EAC62100 adopts eight DDR4 SO-DIMM sockets and supports up to 256GB memory. Server grade SKU solutions are suitable for factory automation applications. Moreover, with the high performance and high-end specifications, GMB-EAC62100 is our first Ice lake-SP platform on Industrial Motherboard product line

Usage Examples

• Compatible with Intel® Ice Lake-SP platform

  • This product is equipped with the 3nd generation Intel® Xeon scalable processor by LGA-4189 socket type CPU, up to 205W TDP design
• BMC function

  • Aspeed AST2500 Advanced PCIe Graphics & Remote Management Processor Onboard Support Baseboard Management Controller for system management and IPMI control
• Support Windows 10 IoT Enterprise LTSC and Windows Server IoT 2019 Standard

  • The LTSC (Long Term Servicing Channel) version of Windows is installed to discourage unnecessary restarts or unwanted feature updates for operational applications. The product has a lockdown function that is useful for the developing secure dedicated terminals. A user can select a language from Japanese, English, Chinese, or Korean in Windows 10 IoT Enterprise 2019 LTSC, and can decide to use Windows Server IoT 2019, which is suitable for edge servers that require server-class multiple processing and network performance.
