SRV-2UN100D 2U Rackmount Server / Intel 5th Gen Dual XEON Processors (Sapphire Rapids) / Up to 10 Hot-Swappable Drives

• Overview / Features
• Specifications
• Ordering Information
• Support / Downloads

Overview / Features

The SRV-2UN100D rackmount server, is designed for workload acceleration with extensive platform innovation, built-in acceleration, and TCO savings. This 2U rackmount server supports Dual Socket (LGA 4677) configurations with 5th and 4th Gen Intel® Xeon® scalable processors. The SRV-2UN100D server is the ideal solution for scalable performance and operational efficiency across diverse workloads in cloud, HPC, AI, deep learning, and networking. This flexible general-purpose server system can support up to 4x single-wide or 2x double-wide graphics cards, 10x hot-swappable drive bays, 16x memory slots (2DPC), and 2x 25GbE with an OCP NIC 3.0 slot option.

• Supports Dual Socket E (LGA 4677) 5th and 4th Gen Intel® Xeon® scalable processors (Codename “Sapphire Rapids”)

  • Supports 5th and 4th Gen Intel® Xeon® scalable processors, Six types of CPU are lined up.
    Xeon Gold 6530 Cores 32T Base 2.1GHz
    Xeon Gold 5520+ Cores 28T Base 2.2GHz
    Xeon Silver 4516+ Cores 24T Base 2.2GHz
    Xeon Silver 4514Y Cores 16T Base 2GHz
    Xeon Silver 4510T Cores 12T Base 2.4GHz
    Xeon Silver 4509Y Cores 8T Base 2.6GHz
• Memory Capacity with 16 +16 DIMM slots (2DPC)

  • 16+16 DIMM slot (2DPC)*1, supporting DDR5 RDIMM/RDIMM-3DS, and Intel's 3rd Generation Optane DC Persistent Memory 'Crow Pass' modules for enhanced data processing and storage capabilities.
    *1 DPC - DIMM per channel.
• Expansion Capabilities for Graphics and Network Connectivity

  • Features 4x FHFL single-slot PCIe5.0 x16 or 2x FHFL dual-slot PCIe5.0 x16 slots, along with 2x OCP NIC 3.0 (PCIe5.0 x16) for network expansion and high-speed connectivity. Equipped with 8x hot-swap 2.5" NVMe (PCIe5.0) drive bays and 2x hot-swap 2.5" SATA drive bays, ensuring rapid data access and flexibility.
• Additional Storage Support to Enhance System Performance

  • Supports 2x M.2 (PCIe4.0 x4) slots for additional SSD storage, enhancing overall system performance.
• Dual Power Supply for Redundancy and Reliability

  • Comes with a 1+1 2700W CRPS power supply for redundancy and reliability.
• Remote Management

  • Includes IPMI for efficient remote server management and monitoring.
