DIO-96D2-LPCI Digital I/O Low Profile PCI card bi-directional 96ch (non-isolated 5VDC-TTL)

• Overview / Features
• Specifications
• Ordering Information
• Support / Downloads

Overview / Features

This product is a Low Profile size PCI bus-compliant interface board that extends the input/output function of bi-directional digital signal. This board has up to 96 unisolated TTL-level input/output channels that is powered by the equivalence to the mode 0 of i8255 chips, and you can use up to 96 channels of the input signals as interrupt inputs. You can select the input/output by the application software in eight signals units (in four signals unit for some inputs/outputs). Additionally, the digital filter function is equipped with this product. Windows/Linux driver is bundled with this product.
Using the dedicated library VI-DAQ makes it possible to create each application for LabVIEW.

• This board can be used to input/output 96 points bi-directional digital corresponding to to the equivalence to the i8255 mode 0.

  • This board has up to 96 unisolated TTL-level input/output channels whose response speed is 200nsec that is powered by the mode 0 of i8255 device for general-purpose.
• You can use up to 96channels of the input signals as interrupt events.

  • You can use up to 96channels of the input signals as interrupt events and also disable or enable the interrupt in bit units and select the interrupt edge.
• This product has a digital filter function to prevent wrong recognition of input signals from carrying noise or a chattering.

  •  This product has a digital filter to prevent input signals from carrying noise or a chattering. All input terminals can be added a digital filter, and the setting can be performed by software.

• Support for both of Low Profile and standard size slots

  • Support for both of Low Profile and standard size slots (interchangeable with a bundled bracket).
