BX-300 BX-300 - Fanless Embedded PC / DIN Rail Mountable / F&eIT Bus / Atom Z530P + US15WP / DC Power Supply

Discontinued

Standard Warranty1 yr

End of Repair Service: 2021/10/29

Check a compatible replacement

* The end of repair date may change depending on the situation.

Contributing to reduction of running cost and promotion of energy efficiency
Compact device design.
Fanless design that reduces maintenance work
Major types of peripherals are supported with rich interfaces including the two CF card slots
Possibly used as a controller for a measurement/control/communication device from the F&eIT Series
Possibly installed in 35mmDIN rail

Ordering Information

Replacement Product

Model	Definition
BX-300 - Fanless Embedded PC / DIN Rail Mountable / F&eIT Bus / PCIe Bus / Atom E3845 (BayTrail SoC) / DC Power Supply BX-320	Architecture is changed. Memory has been increased to 4GB. Two CFast slots are equipped. And the dimensions are not the same as the BX-300. Please refer to the manual for details.

Ordering Information

Model	Description	Certification
BX-300-DC5000	Fanless Embedded PC BX300 series with Atom Z530P 1.60GHz, Without OS
BX-300-DC5311	Fanless Embedded PC BX300 series with Atom Z530P 1.60GHz, WES2009(ja/CF 2GB)

Options

Analog I/O

Item	Item Name
ADI12-8(FIT)GY	Analog Input F&eIT I/O Module / 8ch(12bit 33.3ks/s) / Bus Isolation
ADI16-4(FIT)GY	Analog Input F&eIT I/O Module / 4ch(16bit 33.3ks/s) / Bus Isolation
DAI12-4(FIT)GY	Analog Output F&eIT I/O Module / 4ch(12bit 100ks/s) / Bus Isolation
DAI16-4(FIT)GY	Analog Output F&eIT I/O Module / 4ch(16bit 100ks/s) / Bus Isolation
PTI-4(FIT)GY	Pt100 Temperature Sensor Input F&eIT I/O Module / 4ch(0.01°C 200s/s) / Bus Isolation

Digital I/O

Item	Item Name
DI-16(FIT)GY	Digital input F&eIT I/O module 16ch (isolated 12 - 24VDC)
DI-32(FIT)GY	Digital input F&eIT I/O module 32ch(isolated 12 - 24VDC)
DI-8(FIT)GY	Digital input F&eIT I/O module 8ch (isolated 12 - 24VDC)
DIO-16/16(FIT)GY	Digital I/O F&eIT I/O module 16ch/16ch (isolated 12 - 24VDC)
DIO-4/4(FIT)GY	Digital I/O F&eIT I/O module 4ch/4ch (isolated 12 - 24VDC / 12 - 48VDC)
DIO-8/8(FIT)GY	Digital I/O F&eIT I/O module 8ch/8ch (isolated 12 - 24VDC)
DIO-8D(FIT)GY	Digital I/O F&eIT I/O module bi-directional 8ch (non-isolated 5VDC-TTL)
DO-16(FIT)GY	Digital output F&eIT I/O module 16ch (isolated 12 - 48VDC)
DO-32(FIT)GY	Digital output F&eIT I/O module 32ch (isolated 12 - 48VDC)
RRY-4(FIT)GY	Reed relay contact output F&eIT I/O module 4ch (isolated - 125VAC - 30VDC)

Counter

Item	Item Name
CNT16-8(FIT)GY	Counter F&eIT I/O module 8ch (16bit Up count 5kHz) / Isolated
CNT24-2(FIT)GY	Counter F&eIT I/O module 2ch (24bit Up/Down count 500kHz) / Incremental encoder interface / Isolated

Motion control

Item	Item Name
SMC-2DL-FIT	High-Speed Motion Control Module (2axes)

Serial comm.

Item	Item Name
COM-1PD(FIT)GY	Serial Communication F&eIT I/O Module RS-422A/485 1ch / Isolation and Surge Protection
COM-2(FIT)GY	Serial Communication F&eIT I/O Module RS-232C 2ch

Storage

Item	Item Name
CF-B	CompactFlash(FIX DISK Spec.)

Extended Warranty Service

Item	Item Name
ESP-F5	Extended warranty service package (5 years service course) (Japan only)
ESP-S1	Extended warranty service package (Extension one year) (Japan only)
