LPC-1800-G Slim tower type computer LPC-1800 / Intel 12&13th Gen. (Alder Lake-S, Raptor Lake-S)

NEW

Standard Warranty2 yrs
Extended WarrantyAvailable

Compatible with Intel® Core ™ processor series Raptor Lake
High-performance graphics with CPU embedded type
Rich variety of interfaces to expand your peripherals freely
The identical dimensions enable easy replacement with the LPC-1700 series

*
For details about an extended warranty, please contact us.

Specifications

Mechanical Design

Mounting	Desktop; Wall Mount

Software Support

Supported OS	Windows 10 IoT Enterprise 2021 LTSC 64-bit

Core System

CPU Generation (Development code)	13th Gen. (Raptor Lake); 12th Gen. (Alder Lake-S)
Processor	Core i7-13700TE; Core i5-13500TE; Core i3-13100TE; Celeron G6900TE
CPU socket	-
Memory	up to 128GB
RAS	Hardware monitor (Fan speed / Temperature / Voltage); Remote power-on; Remote reset; Watchdog timer
GPU	-
AI Performance	-
Security	TCG TPM 2.0

Interface

Video	1x DisplayPort; 1x HDMI; 1x DVI-I
LAN	2x 2500BASE-T/1000BASE-T/100BASE-TX/10BASE-T; 1x 1000BASE-T/100BASE-TX/10BASE-T
Wireless	-
Audio	1x Line out; 1x Line in; 1x Mic-in
I/O	6x USB3.2 Gen2 (USB3.1); 2x USB3.2 Gen1; 1x RS-232C/422A/485
Memory card	-

Expansion Slot

Expansion bus	1x PCI Express 4.0(x16); 2x PCI Express(x4); 1x PCI
Drive bay	2x 3.5-inch bay (SATA)

Power

Input voltage	100 to 240VAC

Environment

Operating temperature	5 to 40°C (41 to 104°F)
Storage temperature	-20 to 60°C (-4 to 140°F)
Standards & Certifications	CE; FCC Class A; UKCA; VCCI Class A
