VPC-1800-G Industrial Computer VPC-1800-G - Slim Tower PC / Intel 12＆13th Gen. (Alder Lake/ Raptor Lake) / 1x PCIe(x1), 2x PCI / 3x PCI

NEW

Standard Warranty1 yr
Extended WarrantyAvailable

Compatible with Intel® Core™ processor series Raptor Lake
High-performance graphics with CPU embedded type
Mirroring (RAID1) supported
Removable storage adopted
Rich variety of interfaces to expand your peripherals freely
The selection of expansion slots from PCI-Express 3.0(x1) or PCI board

*
For details about an extended warranty, please contact us.

Specifications

Mechanical Design

Mounting	Desktop; Wall Mount

Software Support

Supported OS	Windows 10 IoT Enterprise 2021 LTSC 64-bit

Core System

CPU Generation (Development code)	13th Gen. (Raptor Lake-S); 12th Gen. (Alder Lake-S)
Processor	Core i7-13700TE; Core i5-13500TE; Core i3-13100TE; Celeron G6900TE
CPU socket	FCLGA1700
Memory	up to 128GB
RAS	Hardware monitor (Fan speed / Temperature / Voltage); Remote power-on; Remote reset; Watchdog timer
GPU	-
AI Performance	-
Security	TCG TPM 2.0

Interface

Video	1x DisplayPort; 1x HDMI; 1x DVI-I
LAN	2x 2500BASE-T/1000BASE-T/100BASE-TX/10BASE-T; 1x 1000BASE-T/100BASE-TX/10BASE-T
Wireless	-
Audio	1x Line out; 1x Line in; 1x Mic-in
I/O	6x USB3.2 Gen2 (USB3.0); 2x USB3.2 Gen1; 3x RS-232C; 1x RS-232C/422A/485
Memory card	-

Expansion Slot

Expansion bus	3 Slots (1x PCI Express(x1), 2x PCI); 3 Slots (3x PCI)
Drive bay	2x 3.5-inch bay (SATA)

Power

Input voltage	100 to 240VAC

Environment

Operating temperature	5 to 40°C (41 to 104°F)
Storage temperature	-20 to 60°C (-4 to 140°F)
Standards & Certifications	CE; FCC Class A; UKCA; VCCI Class A
