VPC-7000-G Industrial Computer VPC-7000 - Desktop / Rackmount PC / Intel 3rd Gen. Scalable Xeon (Ice Lake-SP + C621A) / 3x PCIe 4.0(x16), 2x PCIe 4.0(x8), 1xPCIe 3.0(x4) / RAID

  • Standard Warranty2 yr
  • Extended WarrantyAvailable
  • モーダルで開く
  • モーダルで開く
  • モーダルで開く
  • モーダルで開く
  • vpc-3000_tdl_rgb_96dpi_500x500モーダルで開く
  • モーダルで開く
  • High-end FA computer compatible with Intel ® Xeon ® Scalable Processor
  • Supports GPU computing
  • Uses highly reliable and long-life parts on the premise of continuous operation for 24 hours
  • Achieves long-term supply and long-term maintenance
  • *
    For details about an extended warranty, please contact us.

Ordering Information

Ordering Information

Model Description Certification
VPC-7000-G VPC-7000 - Desktop / Rackmount PC / Intel 3rd Gen. Scalable Xeon (Ice Lake-SP) / 3x PCIe4.0(x16), 2x PCIe4.0(x8) 1xPCIe3.0(x4) / RAID
  • FCC compliant
  • CE marking
  • VCCI

BTO Model

This product is ordered by BTO (Build to Order) method. Please inform the dealer about the BTO menu and request a quotation. *1

CPU
  • Xeon Gold 6330
  • Xeon Gold 6354(Last Order: 30 Nov, 2025)
  • Xeon Platinum 8352Y(Last Order: 30 Nov, 2025)
Memory
  • 32GB
  • 64GB
  • 128GB
  • 256GB
Storage 1(M.2)
  • 2TB SSD
  • 512GB SSD
  • None
Storage 2 ※2
  • 3.5 inch HDD 4TB / Removeable
  • 2.5 inch SSD 256GB /Removeable
  • 2.5 inch SSD 512GB / Removeable
  • None
Storage 3 ※２※3
  • 3.5 inch HDD 4TB / Removeable
  • 2.5 inch SSD 256GB /Removeable
  • 2.5 inch SSD 512GB / Removeable
  • None
Storage 4 ※2※3
  • 3.5 inch HDD 4TB / Removeable
  • 2.5 inch SSD 256GB /Removeable
  • 2.5 inch SSD 512GB / Removeable
  • None
Storage 5 ※2※3
  • 3.5 inch HDD 4TB / Removeable
  • 2.5 inch SSD 256GB /Removeable
  • 2.5 inch SSD 512GB / Removeable
  • None
Boot Drive
  • Storage 1
  • Storage 2
  • None
Optical drive
  • DVD Super Multi Drive
  • None
RAID
  • Software RAID(RAID1)
  • Software RAID(RAID5)
  • Software RAID(RAID10)
  • None
OS
  • Windows 10 IoT Enterprise 2019 LTSC 64-bit (English/Chinese/Japanese/Korean)
  • Windows Server IoT Enterprise 2019 Standard
  • None
Option

*1 There are combinations that can not be configured. Please inquire in detail.
*2 Only the same model can be selected for the drives of storage 2-5.You cannot select a different model.
*3 For RAID, storage 2-5, 3.5 inch HDD 4TB can be selected.

Options

Storage

Item Item Name
HDD-4TS-3 3.5-inch 4TB SATA Hard Disk Drive
HDD-4TS-3R 3.5-inch 4TB SATA Hard Disk Drive, RAID
