SPT-200A-22TR STAND-PC SPT-200A - All-in-One PC / 21.5-inch VA LCD with optical 2 points touch panel / Core i (Coffee Lake) / with AC Adapter

  • Limited Stock
  • Standard Warranty3 yrs
  • Extended WarrantyAvailable
  • End of Repair Service: 2029/02/02

Check a compatible replacement

* The end of repair date may change depending on the situation.

  • Shipped to your door already assembled as an “All-in-One” PC
  • High-performance optical touch-panel display
  • PC unit installed to the base for a stable structure with a low center of gravity
  • New enclosure structure for high-performance CPU
  • Reduced operating costs thanks to a long-term, stable supply
  • Pre-installed with Windows 10 IoT Enterprise—the OS for the latest in embedded devices
  • *
    For details about an extended warranty, please contact us.

Similar Models

Ordering Information

Replacement Product

Model Definition
STAND-PC SPT-200A - All-in-One PC / 21.5-inch IPS LCD with PCAP 10 points touch panel / Core i (Coffee Lake) / with AC Adapter
SPT-200A-22TP
For details, please see datasheets and manuals.

Ordering Information

Model Description / Certification
STP-200A-22TR [Limited Stock] [End of Repair Service : 2 February, 2029] STAND-PC SPT-200A - All-in-One PC / 21.5-inch VA LCD with optical 2 points touch panel / Core i (Coffee Lake) / with AC Adapter
  • CE marking
  • FCC compliant
  • VCCI

BTO Select Menu

This product is ordered by BTO (Build to Order) method. Please inform the dealer about the BTO menu and request a quotation.

CPU
  • Core i5-8500T
    6 cores 6 threads
    2.10GHz(Max turbo frequency 3.50GHz)
    vPro technology
  • Core i3-8100T
    4 cores 4 threads
    3.10GHz
  • Celeron G4900T
    2 cores 2 threads
    2.90GHz
Memory
  • 8GB (DDR4 8GB x 1)
  • 16GB (DDR4 8GB x 2)
Storage 1 (OS)
  • 128GB SSD (M.2)
  • 128GB SSD (SATA)
  • 500GB HDD (SATA)
Storage 2
  • 128GB SSD (M.2)
  • 128GB SSD (SATA)
  • 500GB HDD (SATA)
  • None
Additional LAN Port *1
  • Gigabit LAN port
  • None
Wireless LAN *2
  • IEEE 802.11 ac/a/b/g/n
  • None
OS
  • Windows 10 IoT Enterprise 2019 LTSC 64-bit (English/Chinese/Japanese/Korean)
  • Windows 10 IoT Enterprise 2019 LTSC 64-bit with Microsoft Edge (Chromium) (English/Chinese/Japanese/Korean)
  • None
Option
  • AC adapter holder
  • VESA bracket of preventing LCD fall *3
  • None
  • *1
    If a Gigabit LAN port is selected for Additional LAN Port, 1) the 128GB SSD (M.2) is not available for Storage 1 (OS) and Storage 2. And 2) the wireless LAN (IEEE 802.11 ac/a/b/g/n) is not selectable.
  • *2
    The wireless LAN installed model is not certified for CE Marking.
  • *3
    This option is recommended if the display is frequently changed to be vertically or horizontally. When the mounting screws of the display arm are removed, the display does not fall, reducing the burden of replacement work.
  • *
    There are combinations that can not configured. Please inquire inquire in detail.
