SRV-2UA100D 2U Edge Server/ AMD Gen EPYC Processors (Genoa) / Three Storage Form Factors Supported

• Overview / Features
• Specifications
• Ordering Information
• Support / Downloads

Overview / Features

The SRV-2UA100D is intended for 5G-based, low latency edge computing solutions that require a compact design—such as industrial sites and retail locations where data is created and analyzed. Its tool-less removal of all storage means simplicity plus the extra security you need. With state-of-the-art technology in a short-depth enclosure, the SRV-2UA100D delivers robust and flexible edge computing to compact deployments. The adaptive nature of its bandwidth and low response time makes it optimized for today's more data-hungry applications like 5G and real-time analysis.

• Supports 4th Gen AMD EPYC™ 9000 series, processors (Codename “Genoa”)

  • Supports 4th Gen AMD EPYC™ 9000 series, Four types of CPU are lined up.
    AMD 9124 Cores 16/32T Base 3.0GHz L3 64MB 200W
    AMD 9384 Cores 32/64T Base 3.1GHz L3 768MB 320W
    AMD 9734 Cores 112/224T Base 2.2GHz L3 256MB 340W
    AMD 9654 Cores 96/192T Base 2.4GHz L3 384MB 360W

• Supports 8x DDR5 RDIMM Memory, and SSD type Gen5 E1.S, E3.S EDSFF, and Gen4 U.2

  • Note: Gen5 EDSFF SSDs offer more flexibility, power, performance, efficiency, and versatility compared to Gen4 SSDs which are currently more affordable.
• Short-depth design for space-critical usage
• Supports up to 2x GPU cards and full drive removal with one lever
• 4 PSU Options: single, redundant/single, and DC input

  • Edge applications – redundant/single (1600W)
    Edge applications – 1200W 1+1
    Training simulation – single PSU (1600W or 1200W)
    Edge applications and vehicle – DC input (1200W)

• Front-to-back airflow and easy swap redundant fans to provide optimal thermals with high air flow

  • Note: Not suitable for open office environment.
