API-CNT(WDM) Windows Driver for Counter Input Driver

  • A maximum of 16 boards are controllable. In addition, the driver enables to control up to 256 boards.
  • The current count values of specified channels can be read.
  • The current status register of specified channels can be read.
  • Preset values can be written to specified channels.
  • Timer can wait for a pre-specified period.
  • An event message can be generated when a time-up, timer halt, or count match occurs.


Software Development Kit

Type Win64 API (WDM); Win32 API (WDM)

Supported Development Environment

Supported Development Environment Python; Visual C#; Visual C++; Visual Basic

Supported OS

Supported OS Windows 11 (64-bit); Windows 10 IoT Enterprise LTSC 2021 (64-bit); Windows 10 IoT Enterprise 2019 LTSC (64-bit); Windows 10 IoT Enterprise LTSB 2016 (64-bit); Windows 10 (64-bit); Windows 10 (32-bit); Windows 8.1 (64-bit); Windows 8.1 (32-bit); Windows 7 (64-bit); Windows 7 (32-bit)

Supported Series
