DX-U1200 Industrial Edge AI Computer DX-U1000 - Fanless Embedded PC / with NVIDIA® Jetson Xavier NX™ / Carmel ARM v8.2 / DC Power Supply

Standard Warranty3 yrs
Extended WarrantyAvailable

Edge AI accelerator equipped with NVIDIA® Jetson Xavier NX™
Long-term supply and maintenance
Highly reliable and long-life components
Two Gigabit LAN ports for alternating connections between different network layers
Flexible installation
Stable operations of this product are possible over a wide range of temperatures from -20 to 60°C .

*
For details extended warranty, please contact us.

BUY NOW - U.S. Customers can purchase online in the Contec Americas eShop

Similar Model

Specifications

Mechanical Design

Mounting	DIN Rail Mount; VESA 100 x 100; Wall Mount

Software Support

Supported OS	Linux Ubuntu; SDK JetPack

Core System

Processor	Carmel ARM v8.2 1.40GHz (6core)
CPU Generation (Development code)	-
CPU socket	-
Memory	8GB
RAS	-
GPU	384 CUDA Core (Volta), 48 Tensor Core
AI Performance	6 TFLOPS (FP16); 21 TOPS (INT8)
Security	-

Interface

Video	1x DisplayPort (v1.4); 1x HDMI
LAN	2x 1000BASE-T
Wireless	-
Audio	-
I/O	1x USB3.2 Gen2 (USB3.1); 1x USB2.0
Memory card	1x Micro SD slot

Expansion Slot

Expansion bus	1x M.2 Key B (2230); 1x M.2 Key E (2230)
Drive bay	-

Power

Input voltage	12 to 24VDC

Environment

Operating temperature	-20 to 60°C(-4 to 140°F) (When mounting a PCIe board : -20 to 50°C(-4 to 122°F)) airflow 0.7m/s　 ; * Derating may occur
Storage temperature	-20 to 60°C (-4 to 140°F)
Standards & Certifications	CE; FCC Class A; UKCA; VCCI Class A
