VPC-1700-G Industrial Computer VPC-1700-G - Slim Tower PC / Intel 8th Gen. (Coffee Lake + Q370) / 1x PCIe(x1), 2x PCI / 3x PCI

• Overview / Features
• Specifications
• Ordering Information
• Support / Downloads

Overview / Features

This product is a BTO industrial computer that is equipped with a 8th generation Intel® Core™ processor series. The Intel® Q370 chipset with DDR4 memory (8GB to 32GB) provides advanced computing and graphical performance. This product features a variety of interfaces such as one each port of DVI-I, HDMI, DisplayPort, four USB3.1 Gen1(USB3.0) ports (rear: 4), four USB2.0 ports (front:2, rear:2), four serial ports (RS-232C/422A/485×1, RS-232C×3), and three 1000BASE-T ports, which can be used in a wide range of embedded applications such as general-purpose PC OS-based controllers and information terminals. Two types of expansion slots are provided: 1x PCI-Express (x1) slot and 2x PCI slots, or 3x PCI slots.

• Intel® Core™ processor series Coffee Lake Supported

  • This product contains a power-saving, high performance 8th generation Intel® Core™ processor and provides advanced computing and graphical performance without consuming massive power. Taking up CPU embedded type can contribute to longer-term product availability.
• High-performance graphics with CPU embedded type

  • Full HD video can be smoothly played with the Intel® HD Graphics 630/610. Furthermore, the product can support full HD outputs from three screens of the DVI-I, DisplayPort, and HDMI.
• Mirroring (RAID1) supported

  • Mirroring (hardware or software option) can be configured to suit the application and ensure the system to be redundant.
• Removable storage adopted

  • The front-accessible 3.5 inch SATA storage supports mirroring and other RAID functions.
• Expand your peripherals with various interfaces

  • Interfaces including DVI-I, HDMI, DisplayPort, 1000BASE-T x 3, USB3.1 Gen1 (USB3.0) x 4, USB2.0 x 4, serial port (RS-232C/RS-422A/RS485 x 1, RS-232C x 3), and audio are provided.
• The selection of expansion slots from 1x PCI-Express(x1), 2x PCI or 3x PCI

  • Expansion slots can be selected from 1x PCI-Express (x1) slot and 2x PCI slots, or 3x PCI slots. The maximum size of the board that can be set is 176(L) x 106(H)[mm].
