VPC-7000-G Industrial Computer VPC-7000 - Desktop / Rackmount PC / Intel 3rd Gen. Scalable Xeon (Ice Lake-SP + C621A) / 3x PCIe 4.0(x16), 2x PCIe 4.0(x8), 1xPCIe 3.0(x4) / RAID

Standard Warranty2 yr
Extended WarrantyAvailable

High-end FA computer compatible with Intel ® Xeon ® Scalable Processor
Supports GPU computing
Uses highly reliable and long-life parts on the premise of continuous operation for 24 hours
Achieves long-term supply and long-term maintenance

*
For details about an extended warranty, please contact us.

Specifications

Mechanical Design

Mounting	Desktop; Rack Mount

Software Support

Supported OS	Windows Server IoT 2019 Standard

Core System

Processor	Xeon Platinum 8352Y; Xeon Gold 6354; Xeon Gold 6330
CPU Generation (Development code)	3rd Gen. Xeon (Ice Lake-SP)
CPU socket	LGA4189
Memory	up to 256GB
RAS	Hardware monitor (Fan speed / Temperature / Voltage); Remote power-on; Remote reset; Watchdog timer
GPU	-
AI Performance	-
Security	TCG TPM 2.0

Interface

Video	1x Analog RGB
LAN	2x 1000BASE-T
Wireless	-
Audio	-
I/O	6x USB3.2 Gen2 (USB3.0); 2x USB2.0; 1x RS-232C/422A/485
Memory card	-

Expansion Slot

Expansion bus	3x PCI Express 4.0(x16); 2x PCI Express(x8); 1x PCI Express(x4)
Drive bay	4x 3.5-inch bays (SATA)

Power

Input voltage	90 to 264VAC

Environment

Operating temperature	5 to 40°C (41 to 104°F)
Storage temperature	-20 to 60°C (-4 to 140°F)
Standards & Certifications	CE; FCC Class A; VCCI Class A
