CPS-MC341-ADSC1-931 CONPROSYS M2M Controller - Integrated Type (FANUC MT-LINKi enabled) / OPC UA / MTConnect / CNC / 1x LAN + HUB / 4x DI / 2x DO / 2x AI / 2x CNT / 1x RS-232C / 1x RS-485

  • Standard Warranty3 yrs
  • Extended WarrantyAvailable
  • Together with OPC UA Server
  • Measurement and Upload
  • Web Monitoring
  • Web Task Script
  • Support a communication protocol MTConnect for machine tools
  • Adaptable to a temperature range between -20 and +60°C
  • *
    For details about an extended warranty, please contact us.

Specifications

Controller Unit

Communication Ports Ethernet (LAN)
Programming CONPROSYS VTC
Stack bus -
Function CDS data transfer (https); CNC link; Modbus/TCP slave; MTConnect Adapter/Agent; OPC UA server

Digital I/O

Input Channels 4-ch
Output Channels 2-ch
Bi-directional I/O Channels -
Response Time (Input) 200μsec (max.)
Response Time (Output) 2msec (max.)
Operating Voltage (Input) 12 to 24VDC; -
Operating Voltage (Output) -
Input Circuit Opto-isolated input (for both current sink and source output)
Output Circuit Semiconductor relay output
Built-in Power Supply 12VDC

Analog I/O

Input Channels Differential 2-ch
Input Range 0 to 20mA
ADC Resolution 12-bit
Sampling Rate -
Buffer Memory -
Output Channels -
Output Range -
DAC Resolution -
Update rate -

Counter

Number of Channels 2-ch
Counting System 24-bit Up count
Response speed 1KHz

Serial Comm.

Number of Channels 1x RS-232C [ASYNC]; 1x RS-422A/485 [ASYNC]
Transmission Speed 300 ~ 115,200bps
Isolation Property Isolated
Transmission Method RS-422A/485 [Asynchronous]
