PPC-100 WinCPU Unit PPC-100 - Fanless Embedded PC / MELSEC-Q Base Unit Compatible / Atom N450 + ICH8M

• Overview / Features
• Specifications
• Ordering Information
• Support / Downloads

Overview / Features

This product is the controller which can be installed with Mitsubishi General programmable controller CPU, MELSEC-Q Series and supports Windows OS. This product can work as the multiple CPU configuration with programmable controller CPU and it realizes the seam less processing of both controlling and computing. It can boot from a built-in SSD and a CF card in a CF card slot (Type I). This product has two LAN ports. They realize the open systems for Web, Internet and Intranet. Embedded-type CPU and chipset have been adopted. The use of readily available parts ensures the ease of the use of the product. In addition, the use of self-customized BIOS allows support to be provided at the BIOS level.

• • MELSEC-Q Series programmable controller CPU modules cover sequence controlling. This CONTECWinCPU module covers computing. The combination of them realizes the seam-less processing of information and control data.
• • Very small Windows OS system (2-slot size of a MELSEC-Q series programmable controller CPU)
• • Adopt Intel(R) Atom processor N450, belonging to energy saving platform. It manages both enough performance and energy saving.
• • Various interfaces are installed as the standard. 1000BASE-T LAN, USB2.0, CF card slot and so on.
• • The use of a Contec-customized BIOS (mfd. By Phoenix-Award) allows the support provided at the BIOS level.
• • A CF card can be installed as an external recording media. The use of it is preferable if it works where shock and vibration are exist and works for a continuous long time.
