EPC-C5000A Embedded-PC EPC-C5000 series - Embedded-PC / Xeon-1290TE / 1x PCIe(x16) / Win10 IoT Ent.2021 / AC power supply

• Overview / Features
• Specifications
• Ordering Information
• Support / Downloads

Overview / Features

This product is a PC for embedded use that is equipped with a processor from the 10th generation Intel® Xeon® or Core™ processor series. Embedded-type chipset and CPU have been adopted. The use of readily available parts ensures the ease of the use of the product. The product is equipped with a PCI-Express (x16) bus slot that can be included with an NVIDIA GPU card. In addition, Contec's unique functions such as "Power Failure Protection", "CONTEC Fast Boot", "Secure Boot USB Key", "Disk Copy", "Self-diagnosis" are available.

Usage Examples

• Compatible with Intel® Xeon® W / Core™ processor series Comet Lake

  • Available with a high-performance 10th generation Xeon® processor or power-saving, high-performance 10th generation Core ™ processor. Adopting embedded-type CPU contributes to a stable supply. The lineup includes 13 CPUs for use in various applications.
• CPU built-in high-performance graphics

  • CPU built-in high-performance graphics CPU corresponds to the Intel® HD Graphics 630/610. Full HD video can be smoothly played. It also supports full HD output of the three-screen with the VGA, HDMI and DisplayPort.
• NVIDIA GPU card available

  • Models equipped with a GPU card will come with an NVIDIA GPU card in the expansion slot. This card can be used for expanded screen output options and data server applications thanks to advanced computing power
• Extend peripherals freely. Rich interface

  • This product is equipped with a variety of expansion interfaces such as VGA, HDMI, DisplayPort, LAN x 3, USB3.2 Gen2 x 6, serial (RS-232C/RS422A/RS-485) x 1, audio, Power SW signal connector. You can assist our use in various scenes.
• Equipped with expansion slots that can house PCI Express (x16) cards

  • The product comes equipped with a PCI-Express (x16) bus slot. The maximum size of cards that can be installed is 167 (L) × 68 (H) mm.
• "Power failure protection system" features power-off without OS shutdown

  • Equipped with the "Power failure protection system" function that protects data and prohibits writing to storage in the event of power failure. Along with the lockdown (disk writing suppression) function of Windows IoT Enterprise, power can be safely turned off without a shutdown process. Moreover, file system damage or data damage caused by sudden power failure can be avoided.
