GPD-U64EM-DC2 GPD-U64EM-DC2 - Flat Panel Display / VESA Mountable / 19-inch LCD / PCAP Touch Screen / DC Power Supply

• Overview / Features
• Specifications
• Ordering Information
• Support / Downloads

Overview / Features

This product is a 19-inch On-Screen Display with a high-performance touch screen. As an indicator you can touch the screen with your finger and operate like a tablet PC, this product can be used to control production lines, provide work instructions, manage access, in addition to operate industrial devices through the screen.

• Projected capacitive (PCAP) touch screen for smooth touch operation

  • The GPD-U64EM-DC2 uses a projected capacitive (PCAP) touch screen that enables 10-point multi-touch operations to create a beautiful display with smooth operability. The panel offers excellent scratch resistance and clarity.
• Compatible with VESA standard (100 x 100 mm)

  • Mounting the device on a VESA arm enables flexible screen angle adjustments even when embedded in a device.
    * The device does not included panel mounting holes. Only VESA mounting is possible.
• IP65 compliant in front panel

  • Front part is dust-proof and splash-proof that is compliant with IP65 Standard.
• Works with 24 VDC power supplies

  • The power supply input supports 24 VDC (±10%, 3-terminal) sources, and the power supply can be shared with other embedded devices.
• Complies with various safety standards

  • The device is compliant with VCCI Class B, FCC Class B, CE marking (EMC Directive Class B, RoHS), and CCC safety standards.
